Pompa Termike Serene Climate
A+++ EfiçencëR32 GazInverter
Efikasiteti
A+++
Kapaciteti
10kW - 24kW
Temperatura Ujit
Deri në 55°C
Gaz
R32
Pompa e Ngrohjes Serene Climate R32 ka një dizajn modern dhe vlerësim A+++. Ajo përdor gazin miqësor për mjedisin R32 dhe teknologjinë inverter, duke siguruar ujë deri në 55°C me konsum të ulët energjie dhe performancë të lartë. Pajisja vjen e kompletuar me:
Pompë qarkulluese të integruar për shpërndarje të barabartë të ngrohjes dhe ftohjes,
Detajet Kryesore
- Klasa e Efikasitetit Energjetik A+++, Ngrohje dhe Ftohje
- Gaz ekologjik R32
- Teknologji Inverter për kursim energjie
- Temperaturë maksimale e ujit 55°C
- Pompë qarkullimi e integruar
- Enë ekspansioni e integruar
- Valvula sigurie të integruara
- Operim i qetë
- Kontroll inteligjent
Zgjidhni modelin:
€3100
| Karakteristika | Serene Climate 10kW | Serene Climate 15kW | Serene Climate 18kW | Serene Climate 24kW |
|---|---|---|---|---|
| Model No. | BLN-010TB1 | BLN-014TB1 | BLN-018TB1 | BLN-024TB3 |
| Power supply (V/Ph/Hz) | 220~240/1/50 | 220~240/1/50 | 380~415/3/50 | 380~415/3/50 |
| Heating Capacity (A7/6°C,W30/35°C) (kW) | 4.20 - 12.20 | 5.30 - 16.50 | 6.20 - 20.50 | 6.50 - 26.10 |
| Heating Power Input (A7/6°C,W30/35°C) (kW) | 0.86 - 2.88 | 1.15 - 4.15 | 1.36 - 5.28 | 1.78 - 6.45 |
| Heating Current Input (A7/6°C,W30/35°C) (A) | 3.82 - 12.77 | 5.10 - 18.41 | 2.31 - 8.96 | 2.87 - 10.35 |
| Heating COP (A7/6°C,W30/35°C) (W/W) | 4.23 - 5.39 | 3.97 - 5.43 | 3.88 - 5.21 | 4.04 - 5.43 |
| Heating Capacity (A7/6°C,W47/55°C) (kW) | 3.85 - 11.20 | 4.90 - 15.10 | 6.30 - 19.90 | 6.90 - 26.10 |
| Heating Power Input (A7/6°C,W47/55°C) (kW) | 1.13 - 3.75 | 1.65 - 5.25 | 1.65 - 6.82 | 1.95 - 8.55 |
| Heating Current Input (A7/6°C,W47/55°C) (A) | 5.01 - 16.6 | 7.32 - 23.30 | 2.80 - 11.58 | 3.15 - 13.80 |
| Heating COP (A7/6°C,W47/55°C) (W/W) | 2.99 - 3.46 | 2.87 - 3.38 | 2.91 - 3.34 | 3.05 - 3.42 |
| Cooling Capacity (A35/24°C,W12/7°C) (kW) | 2.60 - 10.30 | 4.50 - 13.50 | 5.50 - 17.50 | 5.20 - 21.30 |
| Cooling Power Input (A35/24°C,W12/7°C) (kW) | 0.91 - 3.65 | 1.45 - 4.85 | 1.65 - 6.25 | 1.95 - 8.20 |
| Cooling Current Input (A35/24°C,W12/7°C) (A) | 4.03 - 16.19 | 6.43 - 21.52 | 2.80 - 10.61 | 3.15 - 13.23 |
| Cooling EER (A35/24°C,W12/7°C) (W/W) | 3.00 | 2.87 | 2.96 | 2.92 |
| ERP Level (Outlet water temp. at 35°C) | A+++ | A+++ | A+++ | A+++ |
| ERP Level (Outlet water temp. at 55°C) | A++ | A++ | A++ | A++ |
| Rated input power (kW) | 3.83 | 6.20 | 7.50 | 10.00 |
| Rated input current (A) | 17 | 27.50 | 35.00 | 17.00 |
| Refrigerant Type / Charge / GWP (... / kg) | R32/1.8/675 | R32/2.8/675 | R32/3.5/675 | R32/3.5/675 |
| Rated water flow (m3/h) | 1.75 | 2.52 | 3.20 | 4.12 |
| Fan quantity | 1 | 1 | 2 | 2 |
| Fan motor type | DC inverter | DC inverter | DC inverter | DC inverter |
| Compressor | Panasonic / DC inverter / Rotary / EVI | Panasonic / DC inverter / Rotary / EVI | Panasonic / DC inverter / Rotary / EVI | Panasonic / DC inverter / Rotary / EVI |
| Circulating pump | Inverter type / Built-in | Inverter type / Built-in | Inverter type / Built-in | Inverter type / Built-in |
| IP Class | IPX4 | IPX4 | IPX4 | IPX4 |
| Sound pressure at 1m distance (dB(A)) | 52 | 53 | 56 | 58 |
| Max outlet water temperature (°C) | 60 | 60 | 60 | 60 |
| Water piping connections (inch) | G1 | G1-1/4 | G1-1/2 | G1-1/2 |
| Pressure drop at rating water flow (kPa) | 27 | 30 | 32 | 35 |
| Operating temperature range(Heating mode) (°C) | -25~45 | -25~45 | -25~45 | -25~45 |
| Operating temperature range(Cooling mode) (°C) | 16~45 | 16~45 | 16~45 | 16~45 |
| Unpacked Dimensions (L*D*H) (mm) | 1100*445*850 | 1110*480*850 | 1110*445*1450 | 1170*445*1450 |
| Packed Dimensions (L*D*H) (mm) | 1160*530*1010 | 1160*565*1010 | 1170*530*1610 | 1170*530*1610 |
| UnPacked Weight (kg) | 107 | 124 | 151 | 160 |
| Packed Weight (kg) | 119 | 136 | 168 | 177 |
